통신케이블 FTP. STP. UTP
                       BELDEN (벨덴) 통신케이블 설명 동영상 (클릭!)  ---> https://www.belden.com/blog/smart-building/stp-utp-ftp-cable-more-7-types-when-to-use-them

1. F/UTP (FTP)

An overall foil shield (F) with unscreened twisted pairs (UTP).
This cable is very much like common UTP cables, with the addition of foil underneath the main cable jacket.
Another common name for this cable is FTP. F/UTP cables are common in 10GBaseT applications.

2. S/UTP

An overall braid screen (S) with unscreened twisted pairs (UTP).
This is occasionally referred to as an STP cable, but beware: There are other shielded cables among this list that may also claim this term.
To be sure, always check to see whether your cable will have any kind of overall barrier, and whether the individual pairs have their own shield.

3. SF/UTP

Both an overall braid screen (S) and foil shield (F) with unscreened twisted pairs (UTP).
This cable is also occasionally referred to as an STP cable.
Cables with an overall braided screen are very effective at protecting EMI from entering or exiting the cable.

4. S/FTP

An overall braid screen (S) with foil screened twisted pairs (FTP).
The “shield” underneath the jacket is a braid, and each individual pair is surrounded by its own foil barrier.
The purpose of the additional foil on individual pairs is to limit the amount of crosstalk between them.

5. F/FTP

An overall foil shield (F) with foil screened twisted pairs (FTP).
Similar to F/UTP cables, these shielded cables are commonly used in 10GBaseT applications.

6. U/FTP

No overall shielding or braid (U) with foil screened twisted pairs (FTP).
This type of shielded cable is commonly used in 10GBaseT applications as well.

7. U/UTP

Notice anything wrong here? You caught us! This cable is not shielded at all, and is the common unshielded cable most often referred to as UTP cable.
